IHF氟塑料離心泵是按標準并結合非金屬泵的工藝設計制造。泵體采用金屬外殼內襯氟塑料（F46/F4/PTFE/PFA），泵蓋、葉輪均用金屬嵌件外包氟塑料（F46/F4/PTFE/PFA）整體燒結壓制而成，軸封采用外裝式的波紋管機械密封，靜環選用氧化鋁陶瓷（或碳化硅），動環采用四氟填充（陶瓷）材料，其密封性。
IHF氟塑料離心泵工作原理：
離心泵的主要過流部件有吸水室、葉輪和壓水室。吸水室位于葉輪的進水口前面，起到把液體引向葉輪的作用；壓水室主要有螺旋形壓水室（蝸殼式）、導葉和空間導葉三種形式；葉輪是泵的重要的工作元件，是過流部件的心臟，葉輪由蓋板和中間的葉片組成。離心泵工作前，先將泵內充滿液體，然后啟動離心泵，葉輪轉動，葉輪的葉片驅使液體轉動，液體轉動時依靠慣性向葉輪外緣流去，同時葉輪從吸入室吸進液體，在這一過程中，葉輪中的液體繞流葉片，在繞流運動中液體作用一升力于葉片，反過來葉片以一個與此升力大小相等、方向相反的力作用于液體，這個力對液體做功，使液體能量而流出葉輪，這時液體的動能與壓能均增大。
IHF氟塑料離心泵用途：
IHF氟塑料離心泵的和已實際使用的證實和廣大用戶的一致認可，已被應用于：化工生產中的腐蝕性介質輸送、離子膜燒堿項目中的氯水廢水處理和加酸工藝（目前國內大部分離子膜燒堿項目用泵均選用我公司產品）、有色金屬冶煉中的電解液輸送、汽車制造中的酸洗工藝，及制藥、石油、電力、電鍍、染料、農藥、造紙、食品、紡織等眾多行業，在-85℃～150℃溫度條件下長期輸送任意濃度的硫酸、鹽酸、氫氟酸、硝酸、王水、強堿、強氧化劑、溶劑、還原劑等強腐蝕介質而毫不受損，是目前受使用單位歡迎的泵類設備之一。
IHF氟塑料離心泵使用注意事項：
1、泵組應水平安裝并固定有穩定的基礎上，且不受其它設備震動的影響；
2、泵組周圍要預留有足夠的空間，以便泵組的維護、檢修；
3、基礎的面積大于泵組底板面積；
4、泵組底板與基礎之間應鋪有可調的襯墊（用于調整泵組的水平）；
5、安裝時應謹慎操作，嚴防工具和雜物落入泵腔內；
6、安裝完畢應檢查聯軸器兩部分（泵聯器和電聯器）有無錯位，如有錯位應調整對中，泵聯器和電聯器之間的間隙以1～2 mm為宜，調好后用手盤動聯軸器，轉動應輕松自如；
7、開機前應按泵組上的箭頭指向調整泵轉向，如果泵反向運轉，將會導致泵組機件損壞。查看泵轉向時不得長時間運轉，防止泵組內因無液潤滑而損壞機械密封。
IHF氟塑料離心泵性能參數：
| 型 號 | 轉速
r/min |
流量Q | 揚程
m |
效率% | 功率 P | 必耐汽
蝕余量 |
||
| m3/h | L/s | 軸功率 | 電機功率 | |||||
| （KW) | ||||||||
| IHF32-25-125 | 2900 | 3.5 | 0.97 | 21 | 40 | 0.5 | 1.5 | 2.3 |
| 5 | 1.39 | 20 | 44 | 0.62 | ||||
| 6.5 | 1.8 | 18 | 42 | 0.76 | ||||
| 1450 | 1.75 | 0.49 | 5.25 | 37 | 0.068 | 0.75 | 2.3 | |
| 2.5 | 0.69 | 5 | 40 | 0.085 | ||||
| 3.25 | 0.9 | 4.5 | 38 | 0.105 | ||||
| IHF32-25-12 | 2900 | 3.1 | 0.06 | 17.6 | 38 | 0.7 | 1.1 | 2.3 |
| 4.5 | 1.25 | 16 | 41 | 0.48 | ||||
| 5.8 | 1.61 | 14.4 | 40 | 0.57 | ||||
| IHF32-25-160 | 2900 | 3.5 | 0.97 | 33 | 34 | 0.93 | 2.2 | 2.3 |
| 5 | 1.39 | 32 | 40 | 1.1 | ||||
| 6.5 | 1.8 | 30 | 42 | 1.26 | ||||
| 1450 | 1.75 | 0.49 | 8.25 | 30 | 0.131 | 0.75 | 2.3 | |
| 2.5 | 0.69 | 8 | 38 | 0.143 | ||||
| 3.25 | 0.9 | 7.5 | 40 | 0.166 | ||||
| IHF32-25-160A | 2900 | 3.1 | 0.86 | 29 | 30 | 0.81 | 1.5 | 2.3 |
| 4.5 | 1.25 | 28 | 35 | 0.97 | ||||
| 5.8 | 1.61 | 26 | 36 | 1.14 | ||||
| IHF40-32-125 | 2900 | 4.4 | 1.22 | 21 | 40 | 0.63 | 2.2 | 2.5 |
| 6.5 | 1.8 | 20 | 45 | 0.79 | ||||
| 8.3 | 2.31 | 18 | 43 | 0.95 | ||||
| 1450 | 2.2 | 0.6 | 5.25 | 37 | 0.085 | 0.75 | 2.5 | |
| 3.25 | 0.9 | 5 | 41 | 0.108 | ||||
| 4.15 | 1.15 | 4.5 | 40 | 0.127 | ||||
| IHF40-32-12 | 2900 | 3.9 | 1.08 | 17.6 | 38 | 0.49 | 1.5 | 2.5 |
| 5.6 | 1.56 | 16 | 42 | 0.58 | ||||
| 7.4 | 2.06 | 14.4 | 40 | 0.72 | ||||
| IHF40-32-160 | 2900 | 4.4 | 1.22 | 33 | 34 | 1.16 | 2.2 | 2.5 |
| 6.5 | 1.8 | 32 | 40 | 1.42 | ||||
| 8.3 | 2.31 | 30 | 39 | 1.71 | ||||
| 1450 | 2.2 | 0.6 | 8.25 | 33 | 0.14 | 0.75 | 2.5 | |
| 2.5 | 0.9 | 8 | 36 | 0.15 | ||||
| 3.25 | 1.15 | 7.5 | 37 | 0.18 | ||||
| IHF40-32-160A | 2900 | 3.9 | 1.08 | 29 | 32 | 0.96 | 1.5 | 2.5 |
| 5.6 | 1.56 | 28 | 38 | 1.23 | ||||
| 7.4 | 2.06 | 26 | 37 | 1.41 | ||||
| IHF50-32-125 | 2900 | 8.8 | 1.08 | 21.5 | 45 | 1.15 | 2.2 | 3.0 |
| 12.5 | 1.56 | 20 | 54 | 1.26 | ||||
| 16.3 | 2.06 | 17.5 | 53 | 1.47 | ||||
| 1450 | 4.4 | 1.2 | 5.37 | 37 | 0.17 | 0.75 | 3.0 | |
| 6.25 | 1.74 | 5 | 46 | 0.18 | ||||
| 8.15 | 2.26 | 4.37 | 45 | 0.22 | ||||
| IHF50-32-12 | 2900 | 8 | 2.22 | 17 | 42 | 0.88 | 1.5 | 3.0 |
| 11 | 3.05 | 16 | 52 | 0.92 | ||||
| 14.5 | 4.03 | 14 | 51 | 1.08 | ||||
| IHF50-32-160 | 2900 | 8.8 | 2.44 | 33 | 41 | 1.93 | 4 | 3.0 |
| 12.5 | 3.47 | 32 | 48 | 2.27 | ||||
| 16.3 | 4.53 | 30 | 47 | 2.84 | ||||
| 1450 | 4.4 | 1.2 | 8.25 | 31 | 0.31 | 0.75 | 3.0 | |
| 6.25 | 1.74 | 8 | 41 | 0.33 | ||||
| 8.15 | 2.26 | 7.5 | 42 | 0.39 | ||||
| IHF50-32-160A | 2900 | 8.2 | 2.28 | 29 | 39 | 1.16 | 3 | 3.0 |
| 11.7 | 3.25 | 28 | 47 | 1.88 | ||||
| 15.2 | 4.22 | 26 | 46 | 2.34 | ||||
| IHF50-32-200 | 2900 | 8.8 | 2.44 | 52 | 34 | 3.7 | 7.5 | 3.0 |
| 12.5 | 3.47 | 50 | 42 | 4.1 | ||||
| 16.3 | 4.53 | 48 | 41 | 5.2 | ||||
| 1450 | 4.4 | 1.2 | 13 | 25 | 0.62 | 1.5 | 3.0 | |
| 6.25 | 1.74 | 12.5 | 33 | 0.65 | ||||
|
8.15 |
2.26 | 12 | 36 | 0.74 | ||||
| IHF50-32-200A | 2900 | 8.2 | 2.28 | 45 | 31 | 3.24 | 5.5 | 3.0 |
| 11.7 | 11.7 | 44 | 40 | 3.5 | ||||
| 15.2 | 15.2 | 42 | 39 | 4.45 | ||||
| IHF50-32-250 | 2900 | 8.8 | 8.8 | 82 | 27 | 7.3 | 11 | 3.0 |
| 12.5 | 12.5 | 80 | 35 | 7.8 | ||||
| 16.3 | 16.3 | 76 | 34 | 10 | ||||
| 1450 | 4.4 | 4.4 | 20.5 | 20 | 1.22 | 2.2 | 3.0 | |
| 6.25 | 6.25 | 20 | 27 | 1.26 | ||||
| 8.15 | 8.15 | 19 | 30 | 1.4 | ||||
| IHF50-32-250A | 2900 | 8.2 | 8.2 | 71 | 25 | 4.53 | 7.5 | 3.0 |
| 11.7 | 11.7 | 70 | 34 | 6.56 | ||||
| 15.2 | 15.2 | 68 | 33 | 8.52 | ||||
| IHF65-50-125 | 2900 | 17.5 | 17.5 | 21.5 | 56 | 1.83 | 3 | 3.5 |
| 25 | 25 | 20 | 64 | 2.13 | ||||
| 32 | 32 | 17.5 | 63 | 2.42 | ||||
| 1450 | 8.72 | 8.75 | 5.37 | 45 | 0.28 | 0.75 | 3.5 | |
| 12.5 | 12.5 | 5 | 57 | 0.3 | ||||
| 16 | 16 | 4.37 | 58 | 0.33 | ||||
| IHF65-50-12 | 2900 | 15.6 | 15.6 | 17 | 53 | 1.36 | 2.2 | 3.5 |
| 22.3 | 22.3 | 16 | 62 | 1.57 | ||||
| 29 | 29 | 14 | 61 | 1.79 | ||||
| IHF65-50-160 | 2900 | 17.5 | 17.5 | 33 | 50 | 3.15 | 5.5 | 3.5 |
| 25 | 25 | 32 | 59 | 3.69 | ||||
| 32 | 32 | 27.5 | 57 | 4.2 | ||||
| 1450 | 8.75 | 8.75 | 8.25 | 40 | 0.49 | 1.1 | 3.5 | |
| 12.5 | 12.5 | 8 | 53 | 0.51 | ||||
| 16 | 16 | 6.87 | 51 | 0.59 | ||||
| IHF65-50-160A | 2900 | 16.4 | 16.4 | 29 | 48 | 2.7 | 4 | 3.5 |
| 23.3 | 23.3 | 28 | 58 | 3.1 | ||||
| 30.4 | 30.4 | 24 | 56 | 3.54 | ||||
| IHF65-40-200 | 2900 | 17.5 | 17.5 | 52 | 45 | 5.5 | 11 | 3.5 |
| 25 | 25 | 50 | 54 | 6.3 | ||||
| 32 | 32 | 45.5 | 54 | 7.35 | ||||
| 1450 | 8.75 | 8.75 | 13 | 36 | 0.86 | 1.5 | 3.5 | |
| 12.5 | 12.5 | 12.5 | 46 | 0.93 | ||||
| 16 | , , ,
16 |
11.4 | 47 | 1.05 | ||||
| IHF65-40-200A | 2900 | 16.4 | 16.4 | 46 | 43 | 4.3 | 7.5 | 3.5 |
| 23.3 | 23.3 | 44 | 53 | 5 | ||||
| 30.4 | 30.4 | 40 | 52 | 5.2 | ||||
| IHF65-40-250 | 2900 | 17.5 | 17.5 | 82 | 39 | 10.1 | 18.5 | 3.5 |
| 25 | 25 | 80 | 50 | 10.9 | ||||
| 32 | 32 | 76 | 52 | 12.74 | ||||
| 1450 | 8.75 | 8.75 | 20.5 | 32 | 1.52 | 3 | 3.5 | |
| 12.5 | 12.5 | 20 | 42 | 1.62 | ||||
| 16 | 16 | 19 | 44 | 1.88 | ||||
| IHF65-40-250A | 2900 | 16.4 | 16.4 | 71 | 36 | 8.8 | 15 | 3.5 |
| 23.3 | 23.3 | 70 | 48 | 9.3 | ||||
| 30.4 | 30.4 | 68 | 50 | 11.25 | ||||
| IHF80-65-125 | 2900 | 35 | 35 | 21.5 | 64 | 3.2 | 5.5 | 4.0 |
| 50 | 50 | 20 | 69 | 3.95 | ||||
| 65 | 65 | 17 | 67 | 4.5 | ||||
| 1450 | 17.5 | 17.5 | 5.37 | 54 | 0.47 | 1.1 | 4.0 | |
| 25 | 25 | 5 | 64 | 0.53 | ||||
| 32.5 | 32.5 | 4.25 | 62 | 0.61 | ||||
| IHF80-65-12 | 2900 | 31 | 31 | 17 | 62 | 2.3 | 4 | 4.0 |
| 45 | 45 | 16 | 68 | 2.88 | ||||
| 58 | 58 | 14 | 67 | 3.3 | ||||
| IHF80-65-160 | 2900 | 35 | 35 | 33 | 60 | 5.24 | 11 | 4.0 |
| 50 | 50 | 32 | 68 | 6.41 | ||||
| 65 | 65 | 27.5 | 67 | 7.27 | ||||
| IHF80-65-160 | 1450 | 17.5 | 4.86 | 8.25 | 50 | 0.78 | 1.5 | 4.0 |
| 25 | 6.9 | 8 | 62 | 0.88 | ||||
| 32.5 | 9 | 6.88 | 61 | 1 | ||||
| IHF80-65-160A | 2900 | 31 | 8.6 | 29 | 58 | 4.1 | 7.5 | 4.0 |
| 45 | 12.5 | 28 | 67 | 5.12 | ||||
| 58 | 16.1 | 24 | 66 | 5.34 | ||||
| IHF80-50-200 | 2900 | 35 | 9.72 | 52 | 52 | 9.53 | 15 | 4.0 |
| 50 | 13.9 | 50 | 64 | 10.64 | ||||
| 65 | 18.1 | 45.5 | 65 | 12.39 | ||||
| 1450 | 17.5 | 4.86 | 13 | 51 | 1.21 | 3 | 4.0 | |
| 25 | 6.9 | 12.5 | 59 | 1.44 | ||||
| 32.5 | 9 | 11.38 | 58 | 1.74 | ||||
| IHF80-50-200A | 2900 | 31 | 8.6 | 46 | 50 | 7.35 | 11 | 4.0 |
| 45 | 12.5 | 44 | 63 | 8.56 | ||||
| 58 | 16.1 | 40 | 62 | 10 | ||||
| IHF80-50-250 | 2900 | 35 | 9.72 | 82 | 40 | 19.4 | 30 | 4.0 |
| 50 | 13.9 | 80 | 50 | 21.8 | ||||
| 65 | 18.1 | 72 | 51 | 25 | ||||
| 1450 | 17.5 | 4.86 | 20.5 | 40 | 2.4 | 4 | 4.0 | |
| 25 | 6.9 | 20 | 50 | 2.7 | ||||
| 32.5 | 9 | 18 | 51 | 3.12 | ||||
| IHF80-50-250A | 2900 | 31 | 8.6 | 71.5 | 39 | 15.4 | 22 | 4.0 |
| 45 | 12.5 | 70 | 50 | 17.6 | ||||
| 58 | 16.1 | 63 | 51 | 19.9 | ||||
| IHF100-80-125 | 2900 | 70 | 19.4 | 23 | 70 | 6.26 | 11 | 5.0 |
| 100 | 27.8 | 20 | 75 | 7.26 | ||||
| 130 | 36.1 | 14 | 65 | 7.63 | ||||
| 1450 | 35 | 9.7 | 5.75 | 65 | 0.85 | 1.5 | 4.5 | |
| 50 | 13.9 | 5 | 70 | 0.97 | ||||
| 65 | 18 | 3.5 | 64 | 0.98 | ||||
| IHF100-80-12 | 2900 | 62.6 | 17.4 | 18 | 68 | 4.5 | 7.5 | 5.0 |
| 89 | 24.7 | 16 | 73 | 5.3 | ||||
| 116 | 32.2 | 11 | 65 | 5.74 | ||||
| IHF100-80-160 | 2900 | 70 | 19.4 | 34 | 68 | 9.53 | 15 | 5.0 |
| 100 | 27.8 | 32 | 74 | 11.78 | ||||
| 130 | 36.1 | 24 | 65 | 13.03 | ||||
| 1450 | 35 | 9.7 | 8.5 | 60 | 1.35 | 2.2 | 4.5 | |
| 50 | 13.9 | 8 | 68 | 1.6 | ||||
| 65 | 18 | 6.5 | 67 | 1.69 | ||||
| IHF100-80-160A | 2900 | 65.4 | 18.2 | 32 | 66 | 8.6 | 11 | 5.0 |
| 93.5 | 26 | 28 | 73 | 9.3 | ||||
| 121 | 33.6 | 21 | 65 | 10.6 | ||||
| IHF100-65-200 | 2900 | 70 | 19.4 | 52 | 64 | 15.5 | 30 | 5.0 |
| 100 | 27.8 | 50 | 72 | 18.91 | ||||
| 130 | 36.1 | 42 | 71 | 20.94 | ||||
| 1450 | 35 | 9.7 | 13 | 60 | 2.06 | 4 | 4.5 | |
| 50 | 13.9 | 12.5 | 68 | 2.5 | ||||
| 65 | 18 | 10.5 | 63 | 2.95 | ||||
| IHF100-65-200A | 2900 | 65.4 | 18.2 | 46 | 63 | 13 | 22 | 5.0 |
| 93.5 | 26 | 44 | 71 | 15.02 | ||||
| 121 | 33.6 | 37 | 70 | 17.4 | ||||
| IHF100-65-250 | 2900 | 70 | 19.4 | 87 | 62 | 26.6 | 45 | 4.0 |
| 100 | 27.8 | 80 | 69 | 31.6 | ||||
| 130 | 36.1 | 68 | 68 | 35 | ||||
| 1450 | 30 | 8.33 | 21.2 | 58 | 3 | 5.5 | 4.5 | |
| 50 | 13.9 | 20 | 63 | 4.3 | ||||
| 60 | 16.7 | 18.5 | 62 | 4.72 | ||||
| IHF100-65-250A | 2900 | 65.4 | 16.2 | 76.5 | 60 | 20.25 | 37 | 4.5 |
| 93.5 | 26 | 70 | 68 | 26.2 | ||||
| 121 | 33.6 | 59 | 67 | 28 | ||||
